Juniper BGP Configuration

This week marked another milestone in our Internet upgrade project, with the completion of a second transit peering to a tier 1 provider. I’m working on a separate post about peering in general, but for now let’s look how it’s done from a Juniper BGP perspective.

Creating a BGP session on a Juniper MX series is a relatively straightforward process, but you need to be careful with routing policies if you don’t want to become transit for your other peers.

transitforpeers

Let’s start by defining a couple of policies. We are receiving full Internet routing tables from our transit provider, so this import policy simply filters out smaller prefixes such as /27-/32. Most transit providers filter out anything smaller than a /24, but this policy just reduces the size of the table if that hasn’t been done upstream. At the time of writing, the full Internet routing table is at 678,760 routes (source). As the number of routes has an impact on router performance, it’s important to keep the table as small as possible.

If your provider is not already doing it upstream, you should also filter for bogons, like the IP ranges used in this post that are reserved for documentation (RFC5737).

[edit policy-options]
policy-statement no-small-prefixes {
	from {
		route-filter 0.0.0.0/0 prefix-length-range /27-/32 reject
	}
}

Set Commands:
set policy-options policy-statement no-small-prefixes from route-filter 0.0.0.0/0 prefix-length-range /27-/32 reject

Next we need a route to announce. It’s a good practice to define either an aggregate route or a static summary discard route (a.k.a null route) when announcing our prefix to the Internet, so that things stay relatively stable.

If we are using only part of the range, those routes will be more specific so will take precedence over the summary route. Anything that comes to us for parts of the range that haven’t been used will simply be discarded.

[edit routing-options static]
route 203.0.113.0/24 discard;

Set Commands:
set routing-options static route 203.0.113.0/24 discard

Now we need a policy to announce the above static route but nothing else. Be very careful here, as the default routing policy action for BGP is as follows.

Readvertise all active BGP routes to all BGP speakers, while following protocol-specific rules that prohibit one IBGP speaker from readvertising routes learned from another IBGP speaker, unless it is functioning as a route reflector.

This means that if we don’t put an explicit reject term below our accept term, the default action will be to advertise all active routes in our table, including any from a second transit peer. This could make our network the better path to some of our other peers, and this is almost certainly not what you want. Thankfully most transit providers will filter on their side as well, but it’s best to make sure with our own policies.

[edit policy-options]
policy-statement announce {
    term 1 {
        from {
            protocol static;
            route-filter 203.0.113.0/24 exact;
        }
        then accept;
    }
    term 2 {
        then reject;
    }
}

Set Commands:
set policy-options policy-statement announce term 1 from protocol static
set policy-options policy-statement announce term 1 from route-filter 203.0.113.0/24 exact
set policy-options policy-statement announce term 1 then accept
set policy-options policy-statement announce term 2 then reject

Now that we have all of our policies in place, it’s time to configure BGP. The configuration below is for a single session with imaginary transit AS65100 from our own imaginary AS65000 (AS numbers 64512 to 65535 are reserved for private use or documentation).

In reality you will probably want multiple external peers for resilience and an internal BGP (iBGP) configuration to distribute those routes around your own network.

[edit routing-options]
autonomous-system 65000

[edit protocols bgp]
group ebgp-65100 {
 type external;
 description "*** eBGP with Transit (AS65100) ***";
 import no-small-prefixes;
 authentication-key "passwordhere";
 export announce;
 peer-as 65100;
 neighbor 198.51.100.1;
}

Set Commands:
set routing-options autonomous-system 65000
set protocols bgp group ebgp-65100 type external
set protocols bgp group ebgp-65100 description "*** eBGP with Transit (AS65100) ***"
set protocols bgp group ebgp-65100 import no-small-prefixes
set protocols bgp group ebgp-65100 authentication-key "passwordhere"
set protocols bgp group ebgp-65100 export announce
set protocols bgp group ebgp-65100 peer-as 65100
set protocols bgp group ebgp-65100 neighbor 198.51.100.1

After committing the above configuration, we can confirm that everything is working with a ‘show bgp summary’.

Peer               AS       Last Up/Dwn  State|#Active/Received/Accepted
198.51.100.1 65100 2d 23:40:54     492395/646126/646006

The number of received routes should be increasing as the full Internet routing table is downloaded.

So, we have confirmed that we are receiving our transit provider’s routes, but what about confirming our outbound announcements? We can use the following command to see that information.

show route advertising-protocol bgp 198.51.100.1

inet.0: 646306 destinations, 1162001 routes (646186 active, 0 holddown, 120 hidden)
Prefix Nexthop MED Lclpref AS path
* 203.0.113.0/24 Self I

You should only see the routes that were previously defined in our ‘announce’ routing policy. If there are more, then there is probably a mistake in the policy. Make sure that you have the second reject term as previously discussed.

We can also check that our announced routes are making their way around the rest of the Internet by using popular looking glass tools such as those listed below.

Happy peering!
